    Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

    Ask Lasest Price
    Brand Name : HORIZON
    Model Number : COLUMN FORMWORKS
    Price : pls ask HORIZON
    Payment Terms : L/C, T/T
    Supply Ability : 200 tons per week
    Delivery Time : 20-25 days
    • Product Details
    • Company Profile

    Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

    Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

    With same components as wall formwork, the column formwork mainly consists of: timber beam H20, steel walers, plywood and beam clamp.


    There are two options of forming columns:

    1). by right-angle waling connector & tie yoke system;

    2). by tie yoke only.

    ComponentsSpecification / description
    Wall formwork panelFor all vertical formworks
    H20 Timber beam

    Water proof treated
    Height: 200mm
    Width: 80mm
    Length: as per table size

    Steel waling

    Painted, powder coated
    [12 steel channel

    Flange clamp

    Galvanized
    To connect steel waling and H20 beams

    Panel strut

    Painted
    help formwork panel erection

    Waling connector 80

    Painted
    Used for formwork panels alignment

    Corner connector 60x60

    Painted
    Used for forming inner corner formwork with wedge pins

    Top scaffold bracket

    Painted,
    severs as safety working platform


    Taking examples as following:

    Column size: 700 x 700mm
    Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

    Column size: 1000 x 500mm
    Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

    Column size: 1000 x 800mm
    Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers

    Column size: 600 x 500mm
    Flexibly Assembled Column Formwork with H20 Wooden Beam and Steel Walers


    Delivery:
    1. Production: For full container, normally we need 20-30 days after receive customer's down payment.
    2. Transportation: It depends on the destination charge port.
    3. Negotiation is needed for special requirements.
